Product Description
The Innuos Zen Mini Mk.II - Your entire music collection on a single, sleek box, ready for playback in any room, any time . Imagine all your CDs available at the press of a button, providing a constantly changing soundtrack for your life.
Gateway server with all the full benefits of innuOS, now with improved connectivity and a new upgrade path for even greater flexibility. Ideal for simple integration into multi-room systems or for those making the first step to a dedicated audio server.
CD Ripper, NAS and Streamer
Compact design with quiet, fanless operation
Versatile HiFi connectivity with analog and digital outputs
Roon Core and Endpoint
Custom audio treated components
Upgradeable with Linear Power Supply
Looking for a tidy solution for all your CDs and the files laying around on the computer? Need an easy way to stream and listen to all your favourite music? Now there’s a simple way to store, manage and play all of it: the ZENmini.
Convenient Design
With its compact footprint, low-power efficiency, quiet operation and range of connectivity, the ZENmini is a convenient and discreet music server for all your Digital Audio needs - from CD ripping to purchased downloads, Internet Radio to Spotify Connect.
Hi-Fi Engineering
The ZENmini offers more than just casual usage. Floating optical and storage drives paired with a custom motherboard and premium components offer far greater musical performance than conventional computers and NAS drives.
Perfect CD Player replacement
Featuring additional Optical and Coaxial digital outputs as well has a high-resolution 24bit/192KHz Digital to Analog Converter (DAC). This means you can now connect directly to all your favourite devices such as Soundbars, AV Receivers or Integrated Amplifiers the easy way.
Powerful Performer
Using our own exclusive innuOS operating system, our servers are configured and optimised from the ground up for the perfect balance of performance and simplicity. Control your library from the comfort of your tablet or smartphone – no computer required.
AUDIO OUTPUTS |
|
Digital Output | USB 2.0 supporting USB Audio Class 2, DoP, Native DSD and MQA |
Coaxial S/PDIF up to 24bit/192KHz | |
Optical S/PDIF up to 24bit/96KHz | |
Analogue Output | RCA Analogue up to 24bit/192KHz |
CONNECTIVITY |
|
Ethernet | 2 x rear panel RJ45 – Bridged Gigabit Ethernet |
USB | 4x USB 3.0 |
FORMATS |
|
CD Formats | Red Book |
Disc Compatibility | CD, CD-R, CD-RW |
Audio format for stored CDs | FLAC (zero compression), WAV |
Audio Formats Supported for streaming and playing | WAV, AIFF, FLAC, ALAC, AAC, MP3, MQA on supported DACs |
SAMPLE RATES |
|
Sample Rates | 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4KHz. 192kHz, 352.8KHz, 384KHz , up to DSD128 via DoP, Native DSD on selected DACs |
Bit Depths | 16bit, 24bit, 32bit |
USER CONTROL INTERFACES |
|
Web Interface | Web Browsers from iOS, Android (4.0 and up) or up-to-date Windows and OS X browsers |
Mobile | App for iPhone/iPad, Android and Windows 10 |
HARDWARE |
|
CD/DVD drive | TEAC Slot-loading drive |
Hard Drive | 1TB WD Red HDD |
CPU | Intel Quad Core N4200 |
Memory | 4GB DDR3 |
STREAMING AND CD STORAGE |
|
UPnP/DLNA | Integrated UPnP Server |
Streaming Services | Qobuz, Spotify Connect, Tidal, Internet Radio |
Roon Compatibility | Roon Core and Roon Bridge |
Average CD Storage Time | 5 minutes |
CD Metadata | FreeDB, MusicBrainz, Discogs, GD3 |
Compatible Music Systems | Sonos Multi-room Wireless Music System |
DLNA/UPnP compatible streamers | |
USB DACs complying to USB Audio Class 2 | |
USB DACs supporting DSD over DoP protocol | |
Selected USB DACs supporting Native DSD | |
REQUIREMENTS |
|
Network | Internet connection to access album metadata when storing CDs, Internet Radio, Streaming Services and software updates |
Network router with at least one available ethernet port | |
Premium subscription required for some streaming services such as Spotify, Qobuz and Tidal | |
Recommended App (USB Connection Only) | iPeng 9 (iOS), OrangeSqueeze (Android), Squeeze Control (Windows 10) |
POWER |
|
Mains Supply | Low ripple Power Adapter, 12V 5A, CEC Level V efficiency |
Power Consumption | 10W when idle, 15W peak |
PHYSICAL |
|
Dimensions | 74 x 214 x 240 mm (H x W x D) |
Weight | 4,5 Kg |
In the box | Innuos ZENmini Mk3 1TB Music Server |
AC/DC Power Adapter | |
Mains Cable | |
2m Ethernet Cable | |
Getting Started leaflet |
Warranty Information
Innuos systems have 2 year warranty for any defective parts or workmanship. If your system is defective, just contact us and we will collect your system via 24h courier, replace any defective parts and return the system via 24 hour courier. Please be aware that if the system is found to be defective due to misuse then all parts, workmanship and shipping must be paid. If this is the case, we will provide you with a budget before starting any repairs.
