Dali Oberon Vokal Centre Speaker
The DALI OBERON VOKAL is designed to be the perfect match with any of the speakers in the OBERON series to form a complete surround system. Delivering a precise, clear and detailed sound performance for both your movie as well concert sound track. The placement of the front-facing bass port on the front baffle supports different placement options in your TV furniture.
We have united the best elements from our current speakers and brought them together in the OBERON VOKAL to deliver on audio quality, looks and versatility. The OBERON VOKAL houses an oversized 29 mm soft dome tweeter together with 2 x 5.25" SMC based wood fibre woofers - supported by the front-facing bass port, which makes the center speaker easy to place. For these reasons, it's the perfect choice for surround setups.
To achieve a wide dispersion pattern in the listening area, the driver materials and geometry applied have been carefully selected. The same principles have been applied in the design of the crossover. As result, you will experience a well-integrated sound, even when listening at a significant off-axis angle. This is important as you are rarely seated directly in front of your loudspeakers when listening to music. An added benefit is seriously reduced harmonic distortion and diffractions causing frequency distortion, as these will always be stronger in an on-axis response. This is also the reason why all DALI loudspeakers are not designed to be toed-in.
|Frequency Range (+/-3 dB) [Hz]||47 - 26,000|
|Sensitivity (2,83 V/1 m) [dB]||89.5|
|Nominal Impedance [ohms]||4|
|Maximum SPL [dB]||109|
|Recommended Amplifier Power [W]||25 - 150|
|Crossover Frequency [Hz]||2,600|
|High frequency driver, Quantity||1 x 29 mm|
|High frequency driver, Diaphragm type||Soft Textile Dome|
|Low frequency driver, Quantity||2 X 5.25"|
|Low frequency driver, Diaphragm type||Wood Fibre Cone|
|Enclosure type||Bass Reflex|
|Bass Reflex Tuning Frequency [Hz]||46|
|Connection Input||Single Wire|
|Recommended Placement||Shelf or stand|
|Recommended Distance From Wall [cm]||0 - 50|
|Dimensions With Base (HxWxD) [mm]||161 x 441 x 295|
Except for the exclusions below, Dali warrants that it will repair or, at its option, replace Dali products as specified below where such Dali product is defective by reason of faulty workmanship or materials, free of charge for parts and labour as follows.
a. Hi-Fi Speakers 5 year warranty, 2 years warranty on all amp modules
